KBK Systems
Double girder suspension cranes
- For loading capacity up to 3200 kg, double-girder cranes allow wider spans than single-girder cranes
- Cost-effective implementation
- Modular system design
- Require no additional supports for the crane runway
BROCHURE DOWNLOAD!
| Technical data |
| KBK section |
Loading capacity [kg] |
Span dimension [m] |
| KBK 100 |
125 |
3,6 |
| KBK I |
125 |
6,2 |
| 250 |
4,7 |
| 500 |
3,2 |
| KBK II-L |
125 |
7,6 |
| 250 |
7,6 |
| 500 |
6,5 |
| 1000 |
4,5 |
| KBK II |
125 |
10,0 |
| 250 |
10,5 |
| 500 |
8,5 |
| 1000 |
6,2 |
| 1600 |
4,6 |
| 2000 |
3,65 |
| KBK II-H |
125 |
10,5 |
| 250 |
10,5 |
| 500 |
10,5 |
| 1000 |
9,1 |
| 1600 |
7,4 |
| 2000 |
6,7 |
| KBK III |
500 |
11,0 |
| 1000 |
9,1 |
| 1600 |
10,0 |
| 2000 |
6,6 |
| 2500 |
5,4 |
| 3200 |
4,2 |
